Peaksonic M4 Bladder Scanner

The  M4 is a handheld portable bladder scanner, which can connect to a phone or tablet, and can be applied in the department of surgery, emergency, ICU, obstetric, gynecology, home health, and nursing homes. It provides basis for clinical catheterization, evaluates the post-void residual after patient urination, and assists to make auxiliary diagnoses of bladder and kidney diseases.

Configuration: Comes with bladder scanner, M4 Probe with internal battery, docking station, Android Tablet with shock resistant case, Charger, PC software for windows operating system, M4 cart, and one bottle of 50ml ultrasound gel.

Scan Modes: 3D Scan

Print Mode: Optional Bluetooth Printer

Working Mode(s): Easy, Expert, and Intelligence Mode

• Cases in Data Storage: 10,000
• Battery Life: 2.3 hours
• Probe Frequency: 2.5 MHz
• Orthorhombic images: 2 inches
• Non-invasive 3D urinary bladder volume measurement
• Volume measurement accuracy: ±7%
• Large data storage space: 10,000+ cases internal storage on phone or tablet
• 1000 patient history information review
• Rapid scanning, measurement results within seconds
• No annual calibration is needed
• WiFi connection to tablet, PC, or mobile phone
• Data transmission: Wifi and PC software included for PDF reports.
• 2-year warranty

Modes selection:

Users can choose between easy, expert, and intelligence mode. When performing a pre-scan, the operator will observe the following exam results:

• Move the probe until the center of the bladder image reaches the green line
• Press scan button once the biggest bladder section is detected
• Twelve real time bladder ultrasonic images will be displayed during scanning
• Volumetric reading is provided along with images and patient information for saving of test
